M/DRAWING REVIEW · ESTIMATING

Your tender queries and BOQ, inside the tender period.

For main contractors, infrastructure and piling subcontractors and rebar fabricators pricing tenders in the UAE, Saudi Arabia and the wider Gulf. Send the package: AI reads every sheet, and an engineer checks the result and signs it off. You get a numbered TQ log before the last date for queries, and the BOQ to POMI or item for item in the client's BOQ.

UNDER NDA · NO FEE, NO COMMITMENT · REPLY WITHIN ONE WORKING DAY · OR BOOK A CALL

First query log
3 days
Traced to a sheet
Every line
Before files move
NDA
Per package
Fixed fee
FIRST PACKAGEYour first Drawing Review is free.One package, such as substructure or drainage, up to 40 sheets, under NDA. The query log and key quantities within 3 working days of the complete package arriving, with a short call to go through them. Or send a tender you've already returned, and we'll check it blind so you can compare.
  1. 01Send the package and the date queries are due
  2. 02We confirm the scope and sign your NDA within one working day
  3. 03Query log and key quantities within 3 working days, then a short call
Send the drawings
M-00/BUILT FORGULF

Main contractors

Several live tenders, incomplete designs and an addendum the week before submission.

Infrastructure and piling

Roads, bridges, utilities, piling and shoring packages, priced fast from the main contractor's tender drawings.

Rebar fabricators

Bar bending schedules per pour, checked against the drawings before anything is cut.

M-01/DRAWING REVIEWSAMPLE

The tender drawings checked before you price, and the queries ready before the clarification deadline.

YOU SEND

The tender package: drawings, drawing list, specification, soil investigation report and BOQ, with the last date for queries.

YOU GET

A tender clarification pack: a numbered tender query (TQ) log in your format, the gaps and conflicts behind each query, the assumptions and exclusions to state in your tender, and key quantities.

  • 01Query logEvery question numbered and written ready to send, referenced to the sheet, revision and clause, in your query schedule format.
  • 02Gaps and conflictsSheets checked against each other, the drawing register and the specification: missing details, clashing dimensions, unstated grades, and notes that conflict with the specification and the codes the project names.
  • 03Assumptions and exclusionsWhere the drawings leave scope open, the basis to state in your tender, so the risk is priced or written down. Where the tender does not allow qualified bids, we turn them into queries instead.
  • 04Key quantitiesConcrete by element, reinforcement allowance by element, excavation and backfill, taken off the drawings so you can sense-check the scope before the full take-off.
Get a free Drawing Review on your next tender
TENDER QUERY LOG · RIVER BRIDGESIGNED OFF
REFSHEETQUERYACTION
Q-01GA-01Pile cap 5100 on plan, 5000 in side viewQuery
Q-08GA-01Casing full depth; spec. needs scour levelVE
Q-16GA-01Borehole B3 level misprinted (87.8)Note

FROM OUR SAMPLE DELIVERABLES, BELOW

M-02/ESTIMATIONSAMPLE

The same drawings taken off into a BOQ, in the format your tender asks for.

YOU SEND

The drawings, the specification and the tender's BOQ or your template.

YOU GET

A BOQ to POMI or item for item in the client's BOQ, every quantity traced to its sheet, with marked-up drawings and the assumptions written down. Priced from your rates or subcontract quotes if you want it.

  • 01Take-off and BOQQuantities taken off to POMI, or item for item in the client's BOQ, and set out in the tender's own BOQ or your template.
  • 02Bar bending schedulesSchedules to BS 8666:2020, or the detailing standard your project names, per pour or per element, with weights by diameter for ordering.
  • 03Marked-up drawingsPDFs showing what was measured where, so your team can check any quantity in seconds.
  • 04AddendaWhen an addendum or tender bulletin lands mid-tender, the affected items are re-measured and the changes listed.
Start with a free Drawing Review
BOQ · POMI · BRIDGE FOUNDATIONSSIGNED OFF
CLAUSEDESCRIPTIONUNITQTY
B15.5Concrete filling to 1200 mm bored piles, C28/35m³1,102.8
C2.2Reinforced concrete C28/35 in pile capsm³578.6
B15.6Cutting off tops of pilesnr42

FROM OUR SAMPLE DELIVERABLES, BELOW

M-S/SAMPLE DELIVERABLESDOWNLOAD
PDF · 5 PAGESTender clarification pack17 of the 23 queries from an overseas river bridge review, with the assumptions and exclusions to state and key quantities.Download PDF · 1 PAGEBOQ excerpt to POMIThe same bridge's foundations and substructure, measured clause by clause to POMI.Download PDF · 10 PAGESBar schedule to BS 8666A sloping wing wall scheduled bar by bar to BS 8666:2020, every varying length listed, with the points to confirm.Download XLSXAll of it in ExcelQuery log, assumptions, key quantities, the POMI and CESMM4 bills and the bar schedule as working spreadsheets.Download

These come from real projects: a river bridge we reviewed overseas and a bridge wing wall, with project names, places and client details removed, and units as on the drawings. On your tenders the method is the same, written to the method of measurement and codes your project names.

Get the same for your tender, freeOne package, up to 40 sheets, under NDA.
M-03/HOW IT WORKS
  1. 01Send the packageDrawings, specification and the date queries are due. We confirm the scope, fee and delivery date within one working day, under NDA.
  2. 02AI first passOur AI reads each sheet, takes off the quantities and cross-checks the drawings against each other, the drawing register and the specification. Anything it can't settle is marked for the engineer.
  3. 03Engineer reviewA senior engineer in the discipline resolves every marked item, checks the result and signs it off.
  4. 04You get the fileIn your format, every line traced to the sheet or clause it came from, and the use of AI stated on the cover.
M-04/STANDARDS AND FORMATS
MeasurementPOMI, CESMM4 or the client's own BOQ, as the tender states
ReinforcementBS 8666:2020 schedules, or the detailing standard your project names, confirmed before we start
Design codesThe codes your project names, such as the Dubai Building Code or the Saudi Building Code
SpecificationsThe project specification, with authority circulars or QCS where the tender names them
ContractsFIDIC-based conditions as amended, and government forms such as the Abu Dhabi Government Conditions of Contract: assumptions and exclusions written to suit

Working to something else? Tell us what your project uses and we’ll confirm it before we start.

M-05/YOUR DRAWINGSHANDLING

NDA first

We sign your NDA, or send ours, before any drawings change hands.

AI use in writing

Every deliverable states what AI did and who checked it.

Senior sign-off

Every package is checked and signed off by a senior engineer in its discipline: bridges, highways or structures.

Never used for training

Your drawings are used for your job only. They are never used to train AI models.

M-06/FROM OUR WORKCASE STUDIES
General arrangement drawing, longitudinal elevation of a six-span bridge on bored pilesA 150 m river bridge, estimated from one drawing150 m SIX 25 M SPANS23 QUERIES RAISEDSame day DRAWING TO ESTIMATERead the case study Wing wall cross-section and reinforcement detailA bar bending schedule for a sloping bridge wing wall5 HEIGHT SEGMENTS1.30 t STEEL SCHEDULED3 POINTS SENT TO THE DESIGNERRead the case study
M-07/QUESTIONS06

Before you send the drawings

Get your first review free

One package from a tender you're pricing now, such as substructure or drainage, up to 40 sheets: the query log, gaps and conflicts, assumptions and exclusions, and key quantities, within 3 working days of the complete package arriving, with a short call to go through them. Or send a tender you've already returned, and we'll check it blind so you can compare our quantities and queries with your own.

AI does the counting: reading each sheet, taking off the quantities, cross-checking the drawings and marking anything it can't settle. A senior engineer in the discipline resolves every marked item, checks the result and signs it off. Each deliverable states what AI did and who checked it.

Yes. We measure to POMI unless the tender issues its own BOQ, in which case we fill that, item for item, and query anything the drawings don't support.

We confirm the scope, fee and delivery date within one working day of receiving the documents. The free review comes back within 3 working days of the complete package arriving. Our fastest estimate so far went from a single drawing to a priced estimate on the same day.

A fixed fee per package, quoted within one working day of receiving the documents. Teams with a steady flow of tenders can take a monthly allowance instead. We don't charge by the hour.

Under NDA, signed before anything is sent. Your drawings are used for your job only and are never used to train AI models. Check your tender's confidentiality terms first: if sharing needs the client's consent, tell us and we'll give you a short description of our handling to send them.
