Every quantity, traced to its drawing.

We read the drawings on Arched, the platform we built for civil take-off, and measure every quantity from what we read. An engineer settles whatever the drawings leave open.

  1. 01

    You send the drawings

    The drawings as issued, in whatever form they come, with your deadline. Questions or a fixed fee back within one working day. An NDA first, if you want one.

    Files received17 FILES · 110 PAGESCURVE REPORTISSUE 120 JulSTRUCTURESISSUE 231 JulISSUE 328 AugCROSS-SECTIONSTYPICAL-CROSS-SECTIONS-AND-SCHEDULE.PDF4 PAGES, IN ISSUE 3ISLAND HIGHWAY01
  2. 02

    We read every page

    Every value keeps the sheet and the place it was read from, and each quantity is measured from those values to the project’s method.

    Typical section TCS-4, wideningCROSS-SECTION SCHEDULE, ISSUE 3EXISTING 3.5CARRIAGEWAY 5.5GRANULAR SUB-BASEps 1.15ps 1.15W 9.48t 0.250.15DEPTHS DRAWN ×422+530 TO 32+460 · L 9,930 ML × (W × t + 2 × ps × 0.15)9,930 × (9.48 × 0.25 + 2 × 1.15 × 0.15)= 26,960m³ISLAND HIGHWAY02
  3. 03

    An engineer settles what’s open

    Where the documents disagree or say nothing, the point is held until an engineer decides it, and the decision is recorded. What only the client can answer becomes a query.

    Box culvert BC-001, at 0+098HELD FOR THE CLIENTTCS-1CULVERT LIST5.51.01.0Reconstruction, hard shouldersTCS-2SCHEDULE, ISSUE 35.51.51.5Built-up, footway and drainCIRCULAR ROAD, 0+000 TO 1+1000+0000+5001+000BC-001BC-002BC-003BC-004≠ISSUE 3 VS 2, BY CONTENTHELDQUERY 1 TO CLIENTITS SHEETS WERE STILL MARKED R0ISLAND HIGHWAY03
  4. 04

    You receive a bill you can trace

    The bill in your format, with measurement records behind every quantity, the queries, and a revision report for every reissue up to submission.

    Bill of quantitiesITEM 3.1 · PART 3: PAVEMENTGranular sub-base, close graded125,320m³TCS-1 68,893TCS-2 3,864 · TCS-3 950.3TCS-4 51,612CIRCULAR ROAD, 0+000 TO 42+6610 km10 km20 km30 km40 kmTCS-426,96018,408TCS-4, +1 STRETCH 6,245BRIDGECULVERTISLAND HIGHWAY04
